3tons LPG Gas Forklift Truck FL30 and with Mast Tilt Angle 6/12 Degree

Model NO. : FL30

Lift height : 3000~5000mm

Condition : New

Product Name : 3tons LPG&Gasoline Forklift Truck FL30

Free Lifting Height : 135mm

Fork Size : 1070*125*45mm

Mast Tilt Angle : 6/12 Degree

Min. Ground Clearance : 120mm

Overhead Guard Height : 2090mm

Front Overhang : 475mm

The Turning Radius : 2400mm

Transport Package : Nude Package

Trademark : SNSC

Origin : China

HS Code : 84270290

Supply Ability : 500/Months

Cab Location : Not Adjustable

Type : LPG Forklift

Power : LP Gas Engine

Load Capacity : 1T - 5T

Fuel : Gasoline

Load center : 500mm

Customization : Available | Customized Request

Place of Origin : china

Brand Name : snsc

Certification : CE/ISO

MOQ : 1 unit

Price : negotiable

Packaging Details : shipped by container

Delivery Time : 30-45 Days

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Contact Now

3tons LPG&Gasoline Forklift Truck FL30
3tons LPG Gas Forklift Truck FL30 and with Mast Tilt Angle 6/12 Degree
3tons LPG Gas Forklift Truck FL30 and with Mast Tilt Angle 6/12 Degree
3tons LPG Gas Forklift Truck FL30 and with Mast Tilt Angle 6/12 Degree
3tons LPG Gas Forklift Truck FL30 and with Mast Tilt Angle 6/12 Degree
3tons LPG Gas Forklift Truck FL30 and with Mast Tilt Angle 6/12 Degree
3tons LPG Gas Forklift Truck FL30 and with Mast Tilt Angle 6/12 Degree
The two units 3tons LPG&Gasoline Forklift Truck FL30 have been sent to Mexico

Details of 3tons LPG&Gasoline Forklift Truck FL30:
Japan NISSAN K25 Engine;
Japan SHIMADZU Hydraulic System(including pumps and valves and oil pipes);
Standard 2-stage 3m mast;
Electric Hydraulic Automatic Transmission by TCM technology;
Lamp protection;
Triangle wide view back mirror;
Waterproof overhead guard;
Backing buzzer and warning light;
Standard Pneumatic Tires

Common Options of 3tons LPG&Gasoline Forklift Truck FL30:
Solid Tires;
3m-7m duplex or triplex full free mast;
Attachments such as paper roll clamp, block clamp, bale clamp, bucket, etc;
Fully closed cabin with heater or air conditioner;
Side shifter and fork positioner;
Fully suspension luxury seat;
Double filter;
High exhaust;
Customized color except green, red and orange.

Specifications of 3tons LPG&Gasoline Forklift Truck FL30:
Specifications Unit FL30
Features Power type LP/Gasoline
Rated load kg 3000
Load center mm 500
Lifting height mm 3000
Free lifting height mm 145
Fork size L*W*T mm 1070*125*45
Mast tilt angle Front/Rear . 6/12
Min. turning radius mm 2400
Min.ground clearance Mast mm 120
Overhead guard height mm 2090
Front overhang mm 475
Performance Max. travelling speed loaded km/h 20
Max. lifting speed loaded mm/s 470
Max. traction force loaded KN 18
Max. climbing ability % 20
Dimension Overall length without fork mm 2695
Overall width mm 1230
Mast lowered height mm 2055
Mast extended height mm 4265
Chassis Tyre Front 28*9-15-12PR
Rear 6.50-10-10PR
Wheel base mm 1700
Wheel thread Front/Rear mm 1000/970
Weight(without load) kg 4350
Powertrain Battery V/AH 12/90
Engine Model nissan K25
Rated power km/r.p.m 37.4/2300
Rated torque Nm/r.p.m 176.5/1600
No. cylinder 4
Bore x stroke mm 89X100
Displacement L 2.488
Fuel tank capacity L 70
Transmission/shift 1/1 automatic transmission
Operation pressure Mpa 17.5

Details of 3tons LPG&Gasoline Forklift Truck FL30:

3tons LPG Gas Forklift Truck FL30 and with Mast Tilt Angle 6/12 Degree

Forklift Catalogue:
Diesel Forklift capacity is from 1.5 ton diesel forklift to 10 ton diesel forklift;
(FD15/FD20/FD25/FD30/FD35/FD40/FD45/FD50/FD60/FD70/FD80/FD100)
Electric Forklift capacity is from 1.5ton battery forklift to 3.5ton battery forklift;
(FB15/FB20/FB25/FB30/FB35)
LPG&Gasoline Forklift capacity is from 1.5ton LPG forklift to 3.5ton LPG forklift;
(FL15/FL20/FL25/FL30/FL35)
Wearhouse material handling equipments include Electric Pallet Truck (TB)/Electric Stacker(DB)/ Electric Reach Truck(YB)/Electric Tractor(QB).
3tons LPG Gas Forklift Truck FL30 and with Mast Tilt Angle 6/12 Degree
Company Introduction:
We, SNSC, are top quality forklift manufacture in China, with 130,000 square meters production area, 30,000 units production capacity per year,5000 sets export volume.
3tons LPG Gas Forklift Truck FL30 and with Mast Tilt Angle 6/12 Degree
We regarde "Quality product, reasonable price, efficient production time and good after-sale servie" as our tenet."
3tons LPG Gas Forklift Truck FL30 and with Mast Tilt Angle 6/12 Degree
We hope to cooperate with more customers for mutual development and benifits. Welcome to contact Winni with your demands.
